main pcb pcb silkscreen specification top layer (branding & functional marking) place the meowkit logo on the top layer with clear visibility use dashed outlines to indicate functional areas (e g , "3m tape"), ensuring no overlap with pads or components bottom layer (traceability information) include standardized production information model (e g , mk s3 ks 1500), revision, author, date, batch, sn (reserved), and qc marking ensure consistent format and readability for manufacturing traceability │ mk s3 ks 1500 rev 5 0 │ author wangte │ date 2026 03 28 / 生产日期 │ batch a01 / 生产批次 │ sn / 序列条形码 │ qc / 质检 pass design rules (readability & manufacturability) maintain minimum silkscreen line width ≥ 0 1mm and text height ≥ 0 8mm keep proper clearance from pads and edges, and ensure all markings remain visible after assembly ┌──────────────┐ │ │ │ │ │ 3m tape │ └──────────────┘ main blocks overview
